Petroleum
We are a highly specialized Physical Commodity Trader of both Crude Oil, its by-products and Global Financial Instruments.
We hold the titles and/or allocations for these commodities and our supplier and clients are direct, established, well-known and trusted companies in the industry. We do NOT deal with broker and intermediary chains. Physical raw commodities successfully traded include Aviation Kerosene Colonial Pipeline Grade 54 Jet Fuel JPA & A-1, Diesel Fuel D2 UAE & USA Gas Oil, Mazut M100, LPG, Saudi & Bonny Light Crude Oil and Kazakhstan Blended Crude Oil
Our accumulation of knowledge in trading commodities combined with our extensive background in the global financial sector and the procurement of excellent relationships with our direct suppliers and buyers, brings very valuable market experience to benefit all transactions in ensuring their successful conclusion.
BCMGLOBAL TRADER is a master limited partnership engaged in the wholesale and commercial distribution of refined petroleum products, and provides ancillary services to companies domestically and internationally. The Company’s business is divided into two segments: Wholesale and Commercial. The Wholesale segment includes sales of gasoline, distillates and residual oil to resellers of transportation fuels, home heating oil retailers and wholesale distributors. The Commercial segment includes sales of unbranded gasoline, home heating oil, diesel, kerosene and residual oil to customers in the public sector and to large commercial and industrial customers, primarily either through a competitive bidding process or through contracts of various terms. This segment also purchases, custom blends, sells and delivers bunker fuel and diesel to cruise ships, bulk carriers and fishing fleets generally by barges. Partnership has three wholly owned operating subsidiaries, The Company’s operations and activities are managed by its general partner, BCM.
The Partnership sells Crude Oil, D2 Diesel Fuel, Jet Fuel, Mazut and Rebco. The Company sells grades of unbranded gasoline. It sells conventional gasoline and ethanol blended gasoline in the markets that require such products. The Company specially blends residual oil for users in accordance with their individual power plant specifications.
Crude oil and oil products such as fuel oil, gasoline, diesel D2 fuel, jet fuel, rebco, liquified petroleum gas and mazut are physically marketed through BCM's commodity sales departments.
To support the activities of these departments, BCM companies holds ownership interests, both directly and indirectly, in several strategically located oil refining operations as well as a diversified portfolio of oil producing assets.
BCM companies' supplies are acquired in part through product produced from its oil pits, long-term contracts from key-producing countries, as well as by traditional short and medium-term purchase agreements. BCM and its subsidiaries deliver to a variety of customers, including the major and medium sized oil companies, Government purchasing agencies and industrial end-users.
Oil and Gas activities are handled primarily by BCM offices in Montreal,quebec .
Click Here to Download the Conversions Table
JET FUEL
What is Jet Fuel? Jet fuel is a type of aviation fuel designed for use in aircraft powered by gas-turbine engines. It is clear to straw colored. The most common fuels are Jet A and Jet A-1 which are produced to an internationally standardized set of specifications. The only other Jet fuel that is commonly used in civilian turbine engine-powered aviation is called Jet B and is used for its enhanced cold-weather performance.
SPECIFICATIONS JET FUEL COLONIAL GRADE 54
Density at 15˜ 0.8 / 0.83 g/ml
DIST_D86 / I.B.P. 159.8
DIST_D86 / 10% recovered 187.4
DIST_D86 / 20% recovered 194.8
DIST_D86 / 50% recovered 208.8
DIST_D86 / 90% recovered 232.7
DIST_D86 / F.B.P. 244.1
DIST_D86 / Residue 1.2 % vol
DIST_D86 / Loss 1.4 % vol
Saybolt Color 28
Appearance Clear & Bright
Flash Point 51.5
Copper Strip Corrosion 2h@100 Class 1
Acid number 0.004 mg KOH
Total Sulphur 0.12 % w/w
Mercaptan Sulphur 0.0005 % w/w
Existent Gum 1mg / 100 mI
FIA / Aromatics 16.5 % vol
Water Reaction : Interface Rating 1
Net Heat of Specific Energy 43.222 ml/kg
Freezing Point -43.5 °C
Kinematics Viscosity @ - 20 6.86 cSt
Smoke point 25 mm
Naphthalene’s 1.2 % vol
JFTOT / Change in pressure drop 1 mm HG
JFTOT / Filter Tube Deposit 1
JFTOT / Tube Appearance 1
MSEP - A 97
Hydrogen Content 13.96 % w/w
Hydro processed fuel in botch 300 % w/w
LNG
What is LNG? Lique fied natural gas or LNG islique fied gas that has been converted temporarily to liquid form for ease of storage or transport. LNG is principally used for transporting natural gas to markets, where it is regasified and distributed as pipeline natural gas. LNG offers an energy density comparable to petrol and diesel fuels and produces less pollution.
SPECIFICATION LNG
Gross Heating Value (Volume Based)
Minimum: 1050 Btu/SCF
Maximum: 1170 Btu/SCF
Hydrocarbon Composition and Nitrogen Content Within the following range:
Methane: 85.00 MOL% Minimum
Butanes and Heavier: 2.0 MOL% Maximum
Pentanes and Heavier: 0.10 MOL% Maximum
Nitrogen: 1.00 MOL% Maximum
Impurities with the following Range:
Hydrogen Sulphide: 4.8 MG/Nm3 Maximum
Total Sulphur: 28.0 MG/Nm3 Maximum SPECIFICATION LNG
Gross Heating Value (Volume Based)
Minimum: 1050 Btu/SCF
Maximum: 1170 Btu/SCF
Hydrocarbon Composition and Nitrogen Content Within the following range:
Methane: 85.00 MOL% Minimum
Butanes and Heavier: 2.0 MOL% Maximum
Pentanes and Heavier: 0.10 MOL% Maximumv
Nitrogen: 1.00 MOL% Maximum
Impurities with the following Range:
Hydrogen Sulphide: 4.8 MG/Nm3 Maximum
Total Sulphur: 28.0 MG/Nm3 Maximum
SPECIFICATION LPG*
Component weight % Propane Iso-butane Normal butane
Methane (C1) NIL - NIL
Ethane (C2) 0.6% max NIL NIL
Propane (C3) 98.9% min 1.2% max NIL
Iso butane (iC4) 0.5% max 95.8% (min) 2% max
Normal butane (nC4) NIL 3% max 96% min
Pentanes (C5) - NIL 1.9% max
Unsaturated hydrocarbons - NIL -
Carbon dioxide (CO2) NIL - NIL
Hydrogen sulphide (H2S) 1ppm max - NIL
Free water -48 Dew pt - -44C Dew pt
*Target: No guaranteed specifications
Mazut
What is Mazut? Mazut is a heavy, low quality fuel oil, used in generating plants and similar applications. When blended the end product is Diesel. Heavy crude oils provide an interesting situation for the economics of petroleum development.
SPECIFICATION
Ash content, not more % 0,14
Mass fraction of sulphur, not more % 0,5
Temperature of the flash, not less °C 110 min
The temperature of solidification, not higher °C 25
Kinematics viscosity 118 max
Water content 0.5%
Mechanical impurities Lower than 0.1%
Acidity Lower than 5 mg KOH/ 100ml
Alkalinity nil
Gross Calorific Value Kcal/kg / KJ/kg min 9200/41300
Density at 15.0 deg. °C Kg/l 0.8900-0.9200
Hydrogen Sulfide Content (H2S) pom 0.5 max
Carbon Residual Lower than 7%
Vanadium (V) ppm 23
Aluminium (Al) ppm 5
Silikon (Si) ppm 12
Nickel (Ni) ppm 49
Asphaltenes m/m 3.6%
Destilation @4 mm Hg
Extracted to 760 mm Hg Initial Boiling Point deg. °C 216
5% recovered deg. °C 259
10% recovered deg. °C 310
Fuel Oil
What is Fuel Oil? Fuel oil is a fraction obtained from petroleum distillation, either as a distillate or a residue. Broadly speaking, fuel oil is any liquid petroleum product that is burned in a furnace or boiler for the generation of heat or used in an engine for the generation of power, except oils having a ash point of approximately 40 °C and oils burned in cotton or wool-wick burners.
SPECIFICATIONS SLCO Saudi Light Crude Oil
API Gravity 33.34
Sediment Content 0.1
ASTM Stabilized Gravity 34.5
Wax Wt. Percentage 9
Vanadium ppm V200 11.0
Gross Heating Value 19.23
Reid Vapor Pressure 2.0
Salt Content ppm NaCI 8
Sulphur Wt, Percentage ` 1.8 Max
Ash ppm 100.0
Comp Carbon Residue Wt. Percentage 3.1
Viscosity CP 55.0
Pour Point 35.0
Diesel (Gas oil)
What is Fuel Oil? Fuel oil is a fraction obtained from petroleum distillation, either as a distillate or a residue. Broadly speaking, fuel oil is any liquid petroleum product that is burned in a furnace or boiler for the generation of heat or used in an engine for the generation of power, except oils having a ash point of approximately 40 °C and oils burned in cotton or wool-wick burners.
SPECIFICATIONS
Centane number, min 45
Distillation, degrees C:
50% max 280
96% (final boiling point) max 360
Kinematic viscosity at 20C, square mm/c, (cst) 3.0-6.0
Sulphur mass, %, max 0.2
Mercaptan sulphur, %, max 0.01
Hydrogen sulphid Abs.
Copper strip test Passes
Water soluble acids and alkalais Abs.
Actual gum content, mg/100 cubic cm, max 40
Acidity, mg/100 cubic cm of gasoil, max 5
Iodine number, g/100 g, max 6
Ash, %, max 0.01
Cokability of 10% residue, max % 0.20
Filtration coefficient, max 3
Sediments Abs.
Water Abs.
Density at 20C, kg/cubic m, max 860
Flash point (closed cup), degrees C, min 62
Pour point from March to October (Summer), degrees C, max -5
Pour point from November to February (Winter), degrees C, max -10
Cloud point from March to October (Summer), degrees C, max 0
Cloud point from November to February (Winter), degrees C, max -5
Commodities Transaction Procedure
When commercial traders enter into a contract for the purchase and sale of goods, they are free to negotiate specific terms of their contract. These terms include the price, quantity, and characteristics of the goods. Every international contract will also contain what is referred to as an Incoterm (international commercial term). The Incoterm selected by the parties to the transaction will determine which party pays the cost of each segment of transport, who is responsible for loading & unloading of goods, and who bears the risk of loss at any given point during a given international shipment. Incoterms also influence Customs valuation basis of imported merchandise. Incoterms are overseen and administered by the International Chamber of Commerce in Paris and are adhered to by the major trading nations of the world. There are currently 13 Incoterms in use, and they can be considered on the basis cited above.
All the current Incoterms are described below :
ExWorks (EXW)
The seller (exporter) makes the goods available to the buyer (importer) at the seller's premises. The buyer is responsible for all transportation costs, duties, and insurance, and accepts risk of loss of goods immediately after the goods are purchased and placed outside the factory door. The ExWorks price does not include the price of loading goods onto a truck or vessel, and no allowance is made for clearing customs. If FOB is the Customs valuation basis of the goods in the country of destination, the transportation and insurance costs from the seller's premises to the port of export must be added to the ExWorks price.
Free Carrier (FCA)
The seller (exporter) clears the goods for export and delivers them to the carrier and place specified by the buyer. If the place chosen is the seller's place of business, the seller must load the goods onto the transport vehicle; otherwise, the buyer is responsible for loading the goods. Buyer assumes ownership/risk of loss from that point forward and must pay for all costs associated with transporting the goods to the final destination.
Free Alongside Ship (FAS)
The seller transports the goods from his place of business, clears the goods for export and places them alongside the vessel at the port of export, where the transfer of ownership and risk of loss shift to the buyer The buyer is responsible for loading the goods onto the vessel (unless specified otherwise) and for paying all costs involved in shipping the goods to the final destination.
Free On Board (FOB)
The seller (exporter) is responsible for delivering the goods from his place of business and loading them onto the vessel of at the port of export as well as clearing customs in the country of export. As soon as the goods cross the «ships-rails» (the ship's threshold) the risk of loss/ownership transfers to the buyer (importer). The buyer must pay for all transportation and insurance costs from that point, and must clear customs in the country of import. An FOB transaction will read «FOB, port of export». For example, assuming the port of export is Boston, an FOB transaction would read «FOB New York». If CIF is the Customs valuation basis, international freight and insurance must be added to the FOB value.
Cost & Freight (CFR)
The seller (exporter) is responsible for clearing the goods for export, delivering the goods past the ships rail at the port of shipment and paying international freight charges. The buyer assumes ownership/bears risk of loss once the goods cross the ship's rail, and must purchase insurance, unload the goods, clear customs, and pay for transport to deliver the goods to their final destination. If FOB is the Customs valuation basis, the international freight costs must be deducted from the CFR price.
Cost, Insurance & Freight (CIF)
The seller (exporter) is responsible for delivering the goods onto the vessel of transport and clearing Customs in the country of export. He is also responsible for purchasing insurance, with the buyer (importer) named as the beneficiary. Transfer of ownership takes place as the goods cross the ship's rail. This if goods are damaged or stolen during international transport, the buyer owns the goods and must file a claim based on insurance procured by the seller. The buyer must clear customs in the country of import and pay for all other transport and insurance in the country of import. CIF can be used as an Incoterm only when the international transport of goods is at least partially by water. If FOB is the Customs valuation basis, the international insurance and freight costs must be deducted from the CIF price. A CIF transaction will read CIF, port of destination. For example, assuming that goods are exported to the port of Novorossiysk, a CIF transaction would read «CIF Novorossiysk».
Carriage Paid To (CPT)
The seller (exporter) clears the goods for export, delivers them to the carrier and is responsible for carriage costs to the named place of destination. Transfer of ownership occurs once the goods are transferred to the carrier and the buyer must insure the goods from that time on. If FOB is the Customs valuation basis, the international freight cost must be deducted from the CPT price.
Carriage & Insurance Paid To (CIP)
The seller transports the goods to the port of export, clears Customs, and delivers them to the carrier. From that point transfer of ownership shifts to the buyer. Seller is responsible for carriage and insurance costs to the named place of destination. The buyer is responsible for all costs, and bears risk of loss from that point forward. If FOB is the Customs valuation basis, international freight and insurance costs need to be deducted from the CIP price.
Delivered At Frontier (DAF)
The seller (exporter) is responsible for all costs involved in delivering the goods to the named point and place at the frontier. Transfer of ownership takes place at the frontier. The buyer must pay the costs and bear the risk of unloading the goods, clearing Customs, and transporting the goods to the final destination. If FOB is the Customs valuation basis, the international insurance and freight costs must be deducted from the DAF price.
Delivered Ex-Ship (DES)
The seller (exporter) is responsible for all costs involved in delivering the goods to a named port of destination. Upon arrival, the goods are made available to the buyer (importer) on-board the vessel. Therefore, the seller is responsible for all costs/risk of loss prior to unloading at the port of destination. The buyer (importer) must have the goods unloaded, pay duties, clear Customs and provide inland transportation & insurance to the final destination.
Delivered Ex-Quay (DEQ)
The seller (exporter) is responsible for all costs involved in transporting the goods to the wharf (quay) at the port of destination. The buyer must pay duties, clear Customs, and pay the cost/bear the risk of loss from that point forward. If FOB is the Customs valuation basis, the international insurance and freight costs, in addition to unloading costs, must be deducted from the DEQ price.
Delivered Duty Unpaid (DDU)
The seller (exporter) is responsible for all costs involved in delivering the goods to a named place of destination where the goods are placed at the disposal of the buyer. The buyer (importer) assumes ownership/risk of loss at that point and must clear Customs and pay duties and provide inland transportation and insurance to the final destination.
Delivered Duty Paid (DDP)
The seller (exporter) is responsible for all costs involved in delivering the goods to a named place of destination and for clearing Customs in the country of import. Under a DDP Incoterm, the seller provides literally door-to-door delivery, including Customs clearance in the port of export and the port of destination. Transfer of ownership occurs when the goods are delivered to the buyer, usually at his premises. Thus the seller bears the entire risk of loss until goods are delivered to the buyer's premises. A DDP transaction will read «DDP named place of destination». For example, assuming goods imported through St. Petersburg are delivered to Moscow, the Incoterm would read «DDP, Moscow». If CIF is the Customs valuation basis, the costs of unloading the vessel, clearing Customs, and delivery to the buyer's premises in the country of destination including inland insurance, must be deducted to arrive at the CIF value.
Crude petroleum, and the refined products made from crude oil, are normally measured either by volume in gallons and US barrels, or by weight in tons or tonnes. The relationship between volume and weight is usually measured by density in the United Kingdom (the alternative measure is relative density or specific gravity). American oilmen usually reckon quantities of oil produced, moved or processed in barrels per day (bpd or b/d). The loose but simple rule of thumb for conversion is that a barrel a day is roughly 50 tonnes a year, but the relationship varies according to density and so according to product.
---------------------------------------------------------------
At 86°F (30°C)
----------- Approximation ------------------
Liters Liters A.Gallons A.Barrels
Product per per per per
Europe.Ton M.Ton M.Ton M.Ton
---------------------------------------------------------------
L.P.G 1,864 1,835 484.6 11.54
JP.4 1,355 1,333 352.4 8.39
Jet A-1 1,274 1,254 331.2 7.89
Premium 1,375 1,353 357.5 8.51
Regular 1,440 1,418 374.5 8.92
Kerosene 1,293 1,273 336.2 8.00
Gas Oil 1,197 1,177 311.2 7.41
Diesel Fuel 1,177 1,159 306.1 7.29
Fuel oil 80 CST 1,082 1,065 281.2 6.70
Fuel oil 180 CST 1,067 1,050 277.4 6.60
Fuel oil 230 CST 1,064 1,047 276.6 6.59
Fuel oil 280 CST 1,061 1,044 275.9 6.57
Bitumen 994 979 258.5 6.15
--------------------------------------------------------------
1 MMSCF of natural gas = 172.3 barrels of crude oil equivalent
= 365 x 1,000,000 scf
1 million cu.ft. of natural gas = 18.91 tons liquid
= 1598.69 cu.ft.liquid
1 std.cu.feet of natural gas = 1000 BTU = 252 kilocalories
1 m.ton of coal = 4.879 barrels of crude oil equivalent
1 m.ton of lignite = 2.053 barrels of crude oil equivalent
1 ltr of fuel oil 1500 sec = 38.9 cubic feet of natural gas
1 kg of LPG = 47.0 cubic feet of natural gas
1 normal cu.m. per day (Nm3/d) = 37.33 standard cu.ft. per day (SCFD)
[flow rate of gas]
1 ton of LNG = 1.14 1.4 x 103 normal cu.m.natural
(LNG conversions) gas (Nm3)
= 52.3 x 103 standard cubic feet natural
gas (SCF)
= 55.0 x 109 joules (HHV)
1 ton of LNG = 1.22 tone crude oil
(Energy equivalents) = 0.80 tone heavy fuel oil
= 0.91 tone LPG (commercial composition)
= 1.91 tone coal
1 barrel per day (b/d) = 50 tones per year (approx.)
1 barrel of oil equivalent = 1 barrel of crude oil
= 5,487 cubic feet of gas
* Natural gas is converted to barrels of oil equivalent using a ratio of 5,487 cubic feet of natural gas per one barrel of crude oil. This ratio is based on the actual average equivalent energy content of Total's natural gas reserves.
1 barrel of crude oil per day = appr. 50 tons of crude oil per year
1 ton of crude oil = 1 metric ton of crude oil
= appr. 7.3 barrels of crude oil (assuming
a specific gravity of 33 API)
= 6.6-8.0 bbl. of crude oil with 7.333 bbl.
Taken as average
= 1.16 kl. of crude oil (average)
1 ton of oil equivalent = appr,1,125 cubic meters of natural gas
MMSCF Million standard cubic feet
CST Centi-Stroke
A. American
E. English
VOLUME 1 American barrel = 158.984 liters
= 42 American (US) gallons
= 34.9726 Imperial (UK) gallons
= 5.6146 cubic feet
= 0.15899 cubic meter
= 3.78541 cubic decimeters (dm3)
= 0.136 tone (approx)
1 American gallon = 231 cubic inches
= 0.133681 cubic foot
= 3.7854 liters
= 0.0238095 American barrel
= 0.83268 Imperial gallon
= 0.0037854 cubic meter
1 Imperial gallon = 277.42 cubic inches
= 1.20094 American gallons
= 4.54609 liters
= 0.028594 American barrel
= 0.160544 cubic foot
= 0.004561 cubic meter
1 liter = 1,000 cubic centimeters
= 1 cubic decimeter (dm3)
= 0.035314 cubic foot
= 61.024 cubic inches
= 1.7597 pints
= 0.219969 Imperial gallon
= 0.26417 American gallon
1 kiloliter = 1,000 cubic decimeters (dm3)
= 6.28981 American barrels
1 gross ton = 100 cubic feet or 2.83 cubic meters of
(Shipping) permanently enclosed space
1 cubic meter = 35.315 cubic feet
= 219.97 Imperial gallons
= 1,000 liters
= 6.2898 American barrels
= 264.17 American gallons
WEIGHT 1 oz. = 28.35 grams
1 lb. = 0.453592 kilograms
= 0.009 cwt.
1 kg. = 2.20462 lb.
= 0.01 quintal
1 cwt = 112 lb.
= 50.802 kg.
1 metric ton = 0.98421 long ton or English ton
= 1.10231 short ton
= 2,204.6 lb
1 English ton = 1.01605 metric tons
or long ton = 1.12 short tons
1 short ton = 0.907186 metric ton
= 0.892857 long ton
= 2,000 lb.
These conversions are based on the assumption that all weights
Are weights in air, which is the correct basis for computing?
Bulk commercial quantities of petroleum
PRICE 1 US cent/AG = 0.42 US$/BBL
1 US$/BBL = 0.163 Baht/Liters
(Based on exchange rate of 25.9 Baht/US$)
PETROLEUM SPECIFIC GRAVITY VOLUME PER TON
----------------------------------------------
Degree Specific Barrels * Long tone
API gravity per metric
Tone
----------------------------------------------
25 0.904 6.98 7.09
26 0.898 7.02 7.13
27 0.893 7.06 7.18
28 0.887 7.10 7.22
29 0.882 7.15 7.27
30 0.876 7.19 7.31
31 0.871 7.24 7.36
32 0.865 7.28 7.40
33 0.860 7.33 7.45
34 0.855 7.37 7.49
35 0.850 7.42 7.54
36 0.845 7.46 7.58
37 0.840 7.51 7.63
38 0.835 7.55 7.67
39 0.830 7.60 7.72
40 0.825 7.64 7.76
41 0.820 7.69 7.81
42 0.816 7.73 7.85
----------------------------------------------
* Approx. figures 60°F
141.5
Specific gravity = ------------
131.5 + °API
POWER AND HEAT UNITS
1 HP (UK Horsepower) = 550 foot pounds per second
= 0.7457 kilowatt
= 1.014 PS (or Cheval Vapeur)
1 PS (Pferdestaerke) = 542 foot pounds per second
or CV (Cheval Vapeur) = 0.986 hp
= 0.736 kW
1 kW (Kilowatt) = 1,000 watts
= 1,340 hp
= 1.359 PS or CV
= 737 foot pounds per second
1 foot pound per second = 0.00136 kilowatt
= 0.00182 hp
= 0.00184 PS or CV
1000 Btu = 0.293 kWh
100,000 Btu = 1 therm
1 calorie (dieticians') = 4.1855 kilojoules
1 Therm = 100,000 Btu (British Thermal Units)
= 25,200 kilocalories
= 25.2 thermies
= 29.3 kilowatt hours
1000 kilocalories = 3,968 Btu
(Large Calories) = 1.163 kilowatt hours
= 1 thermie
1 kilowatt hour = 3,411 Btu
= 1.340 hp hours
= 859.6 kilocalories
LIQUEFIED METHANE
1 Ton of Liquefied = approximately 16 barrels
Methane = approximately 50,000 cubic feet
(1400 cubic meters) of natural gas,
Depending on methane content
PRODUCT SPECIFIC GRAVITY RANGES
---------------------------------------------------
Spec. Barrels per
Gravity metric ton
---------------------------------------------------
Crude oils 0.80-0.97 8.0-6.6
Aviation gasoline's 0.70-0.78 9.1-8.2
Motor gasoline's 0.71-0.79 9.0-8.1
Kerosines 0.78-0.84 8.2-7.6
Gas oils 0.82-0.90 7.8-7.1
Diesel oils 0.82-0.92 7.8-6.9
Lubricating oils 0.85-0.95 7.5-6.7
Fuel oils 0.92-0.99 6.9-6.5
Asphaltic bitumen's 1.00-1.10 6.4-5.8
---------------------------------------------------
CALORIFIC VALUE OF FUElS
Rough gross values in Btu per lb
-------------------------------------
Crude oils 18,300-19,500
Gasoline's 20,500
Kerosene's 19,800
Benzole 18,100
Ethyl alcohol 11,600
Gas oils 19,200
Fuel oils (bunker) 18,300
Coal (bituminous) 10,200-14,600
LNG 22,300
LPG (butane) 21,300
-------------------------------------
TYPICAL PROPERTIES OF EXPORT STREAMS
----------------------------------------
MIRI Bintulu Labuan
----------------------------------------
API Gravity 33° 35° 32°
Pour Point 45°F 15°F 45°F
Wt. % Sulphur 0.07 0.1 0.07
----------------------------------------
PRESSURE>
1 Bar = 0.987 atmospheres
= 750.1 mm Hg
= 14.50 pound/sq inch
= 1.020 kg force/sq cm
1 kg force/sq cm = 14.22 pounds/sq inch
1 pound/sq inch = 0.070 kg force/sq inch
HEAT AND ENERGY
1 megajoule = 238.8 kilocalories
= 947.8 British Thermal Units
= 0.278 kilowatt hours
1 terajoule = 0.00002388 Mtoe
1 kilocalorie = 3.968 Btu
= 4186 joules
= 1.163 x 10-3 kWh
1 kilowatt hour = 859.8 kilocalories
= 3412 Btu
1 million Btu = 1055 megajoule
= 2520 megacalories
= 293.1 kilowatt hours
1 ton of oil equivalent = 10000000 kilocalories
(Ton) = 41.868 gigajoules
= 40.047 x 106 BTU
= 42.244 GJ
INTER FUEL CONVERSION FACTOR
Whilst individual crude's, coals and gases vary widely in quality,
Certain standard qualities are often assumed for statistical
Purposes:
-----------------------------------------------------------------
Reference Barrel Oil Ton Oil Ton Coal 1,000 Cubic
Fuel Equivalent Equivalent Equivalent Feet Natural
Gas
-----------------------------------------------------------------
Calorific 5.8x106 43x106 7x106 1x106
Value Btu gross Btu gross Kcal net Btu gross
Conversion 1 0.14 0.21 5.8
Factors 7.41 1 1.57 43.0
4.71 0.64 1 27.3
0.17 0.02 0.04 1
-----------------------------------------------------------------
Based on these qualities, the following equivalent rates of
consumption can be used with reasonable accuracy:
-----------------------------------------------------------------
LNG NG OIL OIL COAL
t/y 106 mmcF/d toe/y boe/y tce/y
109 Nm3/y
-----------------------------------------------------------------
1 1.41 1.22 25 1.9
0.71 1 0.87 18 39
0.82 1.15 1 20 1.55
0.04 0.056 0.049 1 0.076
0.53 0.74 0.64 13 1
-----------------------------------------------------------------
CALORIFIC VALUE
1 megajoule/cu m = 25.84 Btu/cu ft
1 megajoule per normal = 25.368 BTU per standard cubic feet
Cubic meter (BTU/SCF)
= 2.388 x 102 kilocalorie per normal
cubic meter (kcal/Nm3)
1 kilocalorie/cu m = 0.016 Btu/cu ft
1 megajoule/kg = 429.9 Btu/pound
1 kilocalorie = 1.8 Btu/pound (exact)
1 Btu/cu ft = 37.38 kilojoules/cu m
= 9.410 kilocalories/cu m
1 Btu/pound = 2.326 kilojoules/kg
= 0.556 kilocalories/kg
ENERGY VALUES
Btu per lb:
Wood: green 4,400
Dry 7,310
Peat, sod 6,200
Lignite 9,000
Coke 12,100
Coal: bituminous 13,000
Anthracite 14,500
Oil: fuel 18,500
Gas 19,500
==============================================================================
NATURAL GAS AND OTHER ENERGY EQUIVALENTS
The following are quick-reference equivalents. All figures are APROXIMATE
VALUES only for use where precision is not required. They are based on:
(i) for natural gas:
1,000 Btu/ft3 = 9,500 kcal/m3 (Groningen gas 8,400 kcal/m3)
(ii) for LPG:
an assumed 50/50 propane/butane mixture with (r) or (p) indicating
That the LPG is either refrigerated or pressurized.
(iii) Calorific values, MMBtu (gross):
per tone - LNG 51.8; LPG 47.3; oil 42.3; coal 27.3
per barrel - LNG 3.8; LPG (r) 4.45; LPG (p) 4.1; oil 5.8
per cubic meter - LNG 23.8; LPG (r) 28; LPG (p) 25.8
Natural Gas: Cubic Meter Equivalents
------------------------------------------------------------------------------
1 mrd m3 Natural Gas per Year
per year = 0.04 Tcf gas (38 trillion Btu)
= 890 000 tones oil
= 800 000 tones LPG
= 725 000 tones LNG
= 1.4 million tones coal
per day = 100 million ft3 gas
= 17 800 barrels oil
= 23 200 barrels LPG (r)
= 25 200 barrels LPG (p)
= 27 200 barrels LNG
1 million m3 Natural Gas per Day
per year = 0.014 Tcf gas (14 trillion Btu)
= 325 000 tones oil
= 290 000 tones LPG
= 265 000 tones LNG
= 500 000 tones coal
per day = 37 million ft3 gas
= 6 500 barrels oil
= 8 500 barrels LPG (r)
= 9 200 barrels LPG (p)
= 9 900 barrels LNG
1 m3 Groningen gas = 0.88 m3 (9 500 kcal)
1 m3 (9 500 kcal) = 1.13 m3 Groningen gas
Natural Gas: Cubic Foot Equivalents
-------------------------------------------------------------------------------
1 Tcf Natural Gas per Year
per year = 27 mrd m3 gas (30 mrd Groningen)
= 24 million tones oil
= 37 million tones coal
per day = 2 700 million ft3 gas
= 470 000 barrels oil
100 MMcf Natural Gas per Day
per year = 0.04 Tcf (37 trillion Btu)
= 1 mrd m3 gas (1.1 mrd Groningen)
= 860 000 tones oil
= 770 000 tones LPG
= 700 000 tones LNG
= 1.35 million tones coal
per day = 2.7 million m3 gas (3 million Groningen)
= 17 250 barrels oil
= 22 500 barrels LPG (r)
= 24 400 barrels LPG (p)
= 26 300 barrels LNG
LNG: Volumetric Equivalents
-------------------------------------------------------------------------------
1 million tonnes LNG per Year
per year = 77 million ft3 (liquid)
= 2.2 million m3 (liquid)
= 14 million barrels (liquid)
= 0.05 Tcf (gas)
= 1.4 mrd m3 (gas)
= 1.1 million tones LPG
= 1.2 million tones oil
= 52 trillion Btu
= 1.9 million tones coal
per day = 140 million ft3 (gas)
= 4 million m3 (gas)
= 37 500 barrels LNG
= 31 900 barrels LPG (r)
= 34 600 barrels LPG (p)
= 24 500 barrels oil
1 million m3 LNG per Year
per year = 460 000 tones LNG
= 6.3 million barrels LNG
= 0.2 Tcf (gas)
= 0.6 mrd m3 (gas)
= 500 000 tones oil
= 560 000 tones oil
= 24 trillion Btu
= 870 000 tones coal
per day = 65 million ft3 gas
= 14 700 barrels LPG (r)
= 15 900 barrels LPG (p)
= 17 200 barrels LNG
= 11 200 barrels oil
m3 = kilolitre
LPG & Ethane: Weight, Volume, Heat Conversions
-------------------------------------------------------------------------------
Barrels Per Tone
Ethane Propane n-Butane C3/C4 mix
Pressured 17.6 12.4 10.8 11.6
Refrigerated 11.5 10.8 10.4 10.6
Cubic Meters Per Tone
Ethane Propane n-Butane C3/C4 mix
Pressured 2.80 1.97 1.71 1.84
Refrigerated 1.83 1.72 1.66 1.69
106 Btu Per Barrel
Ethane Propane n-Butane C3/C4 mix
Pressured 2.79 3.85 4.35 4.10
Refrigerated 4.27 4.41 4.49 4.45
106 Btu Per Cubic Meter
Ethane Propane n-Butane C3/C4 mix
Pressured 17.6 24.2 27.4 25.8
Refrigerated 26.9 27.7 28.3 28.0
106 Btu Per Tone
Ethane Propane n-Butane C3/C4 mix
Pressured } 49.2 47.7 46.9 47.3
Refrigerated}
1 Barrel/Day = Tones Per Annum
Ethane Propane n-Butane C3/C4 mix
Pressured 20.7 29.4 33.8 31.6
Refrigerated 31.7 33.8 35.0 34.4
Natural Gas: Inter-Fuel Price Equivalents (US Currency)
-------------------------------------------------------------------------------
ONE CENT per MMBtu
= 5.8 Cents per Barrel crude oil
= 6.4 Cents per Barrel fuel oil
= 5.2 Cents per Barrel naphtha
= 4.5 Cents per Barrel LPG (r)
= 4.1 Cents per Barrel LPG (P)
= 3.8 Cents per Barrel LNG
ONE CENT per MMBtu
= 0.42 Dollars per Tone crude oil
= 0.40 Dollars per Tone fuel oil
= 0.45 Dollars per Tone naphtha
= 0.47 Dollars per Tone LPG
= 0.52 Dollars per Tone LNG
ONE DOLLAR per BARREL
= 17 Cents per MMBtu crude oil
= 16 Cents per MMBtu fuel oil
= 19 Cents per MMBtu naphtha
= 22 Cents per MMBtu LPG (r)
= 24 Cents per MMBtu LPG (p)
= 26 Cents per MMBtu LNG
ONE DOLLAR per TONNE
= 2.4 Cents per MMBtu crude oil
= 2.5 Cents per MMBtu fuel oil
= 2.2 Cents per MMBtu naphtha
= 2.1 Cents per MMBtu LPG
= 1.9 Cents per MMBtu LNG
ONE CENT per US gallon LPG = 10 CENTS per MMBtu
Oil and Coal Equivalent
-------------------------------------------------------------------------------
1 million tones Oil per Year
per year = 1.1 mrd m3 gas (1.3 mrd Groningen)
= 1.5 million tones coal
= 815 000 tones LNG
= 890 000 tones LPG
= 0.04 Tcf gas (42 trillion Btu)
per day = 115 million ft3 gas
= 3 million m3 gas
= 30 500 barrels LNG
= 26 000 barrels LPG (r)
= 28 300 barrels LPG (p)
= 20 000 barrels oil
1 million tones Coal per Year
per year = 0.7 mrd m3 gas (0.8 mrd Groningen)
= 640 000 tones oil
= 525 000 tones LNG
= 580 000 tones LPG
= 0.03 Tcf gas (27 trillion Btu)
per day = 75 million ft3 gas
= 2 million m3 gas
= 19 700 barrels LNG
= 16 800 barrels LPG (r)
= 18 200 barrels LPG (p)
= 12 900 barrels oil
10 000 barrels Oil per Day
per year = 0.6 mrd m3 gas
= 500 000 tones oil
= 780 000 tones coal
= 0.02 Tcf gas (21 trillion Btu)
per day = 58 million ft3 gas
= 1.5 million m3 gas
---------------------------------------------------------------------------
Rich Gas = natural gas having a gross calorific value of 41,868 kJ/m3.
This term is used particularly for the natural gas from the North Sea and
from Algeria.
Degree-days = the number of degree-days of a day is calculated on the
Basis of a reference temperature set by experience at 16.5 C;
it gives the difference between
that reference temperature and the daily mean temperature if the latter
is the lower.
The number of degree-days of a year is the sum of the degree-days registered for
each day of that year.
G-factor = invoicing factor representing the average monthly cost of
Natural gas at the Belgian border in francs per gigajoule
1GJ 1Gcal 10-6 Btu 1toe 1kWh 1m3
------------------------------------------------------------------------------
1GJ 1 0.239 0.948 0.024 277.778 23.884
1Gcal 4.186 1 3.967 0.1 1,163 100
10-6 Btu 1.055 0.252 1 0.025 293.1 25.2
1toe 41.855 10 39.671 1 11,626 1,000
1kWh 3.600 10-3 0.860 10-3 3.421 10-3 0.083 10-3 1 86.011 10-3
1m3 rich gas 0.042 0.010 0.040 0.001 11.626 1
-------------------------------------------------------------------------
Gigjoule giga British ton oil kilowatt
Calorie thermal equivalent - hour Unit
LEGAL DISCLAIMERS & NOTICES
THIS SITE IS PROVIDED BYBCM GLOBAL TRADER ON AN "AS IS" BASIS. NO REPRESENTATIONS GUARANTEES OR WARRANTIES OF ANY KIND, EXPRESSED OR IMPLIED, AS TO THE OPERATION OF THIS SITE, THE INFORMATION, CONTENT, MATERIALS OR PRODUCTS OR SERVICES THAT MAY BE INCLUDED ON THIS SITE(S) ARE MADE.BCM GLOBAL TRADER WILL NOT BE HELD LIABLE FOR ANY DAMAGES OF ANY KIND ARISING FROM THE USE OF THIS SITE, THE ACQUISITION OF ANY COMMODITY, OR OTHER SERVICE PROVIDED, OR AS A RESULT OF ANY GUIDANCE AND/OR ANY CONSULTATION WITHBCM GLOBAL TRADER OR ONE OF ITS SISTER SITES. THIS INCLUDES BUT IS NOT LIMITED TO DIRECT, INDIRECT, INCIDENTAL, PUNITIVE AND CONSEQUENTIAL DAMAGES.
BE ADVISED THAT IT IS YOUR RESPONSIBILITY TO CONSULT WITH YOUR ATTORNEY AND/OR LEGAL REPRESENTATIVE BEFORE ENGAGING IN ANY TYPE OF TRANSNATIONAL TRANSACTION. IT IS RECOMMENDED THAT YOU SEEK AND OBTAIN THE ASSISTANCE OF A PROFESSIONAL TO ASSIST YOU AND GUIDE YOU THROUGH THE ENTIRE PROCESS.
BE FURTHER ADVISED THATBCM GLOBAL TRADER RESERVES THE RIGHT, BASED ON ITS OWN DISCRETION TO FOLLOW UP ON ANY PROSPECTIVE INQUIRIES MADE BY ANY PARTIES. BCM GLOBAL TRADER HAS A STRINGENT COMPLIANCE AND DUE-DILIGENCE PROCEDURE AND UNDER SUCH GUIDELINES IT RESERVES THE RIGHT TO PROCEED WITH ANY INQUIRY OR NOT. BCM GLOBAL TRADER IS NOT UNDER THE OBLIGATION OR DUTY TO FOLLOW UP WITH ANY PROSPECTIVE INQUIRIES UNLESS IT DOES SO AT ITS OWN DISCRETION.
USER TERMS
Please read carefully the following terms and conditions of use, a legal agreement between you ("User") andBCM GLOBAL TRADER .
Welcome to the BCM GLOBAL TRADER site. The following terms and conditions (the "Agreement") govern any viewers, users or visitors-i.e., your use of the Site. Please read this agreement carefully and be advised that your use of this site or any other sites owned and operated by BCM GLOBAL TRADER constitutes your acceptance of the terms and conditions of the Agreement and your consent to be bound by the Agreement.
Please note that from time to time, and without any notice to you, we reserve the right to revise or modify the Agreement with certain additions, deletions or changes. Your future usage of our Site(s) following any changes constitutes your acceptance to be bound by such a revised or modified Agreement. Unless otherwise agreed upon in writing, this is the only Agreement between you and BCM GLOBAL TRADER .
You agree to read the entire agreement(s) before using this Site. You must accept its terms and conditions as they are binding. If you do not accept the terms, you may not access or otherwise use this Site or any other Sites owned or operated by BCM GLOBAL TRADER . If at any time, a provision or portion of the Agreement is demonstrated to be unenforceable, that particular part will be deemed void but will not affect the validity of the remaining provisions. All contents included in this Site, including but not limited to, text, graphics, images, designs, photograph(s), software, as well as the compilation of all the content and the way it is arranged, is the property of BCM GLOBAL TRADER and protected by all applicable United States and International infringement and copyright laws.
You do not acquire any ownership rights to the content or material available on this Site. Any reproduction, modification, distribution, republication or transmission of the contents on this Site, or any other Site owned or operated by BCM GLOBAL TRADER or any derivative work or developments from any of the contents of this Site or any other Sites owned or operated by BCM GLOBAL TRADER is strictly prohibited. You acknowledge that your use of this Site, or any other Site owned or operated by BCM GLOBAL TRADER is done at your own risk. The Site(s) may contain errors, problems or may have been infiltrated by a virus or bug. It may have other problems or limitations.BCM GLOBAL TRADER does not warrant that the functions contained in the Site(s) or any materials or content contained therein will be uninterrupted or error free, that the defects will be corrected, or that the site(s) or the server that makes it available is free of any harmful components.BCM GLOBAL TRADER assumes no liability or responsibility for any damages arising from your use of this site(s).
In no event will BCM GLOBAL TRADER be held liable to any given party for direct, indirect, special, incidental, consequential, or any other types of damage for any use of this Site, or any other Site owned or operated by BCM GLOBAL TRADER , including without limitation, any lost profits, business interruption, harm to equipment or otherwise. Links that lead to other companies or sites that are not affiliated to BCM GLOBAL TRADER are not to be regarded as product or service endorsements.BCM GLOBAL TRADER does not in any way control the content in the links. Any concerns should be addressed to the particular Sites in question. As a user, you represent that you will not engage in actions that may be harmful to the Site(s). You agree that this agreement will be treated as though it were executed in the State of MONTREAL,QUEBEC, and will be governed by and construed in accordance with the laws of the United States of America and the State of MONTREAL,QUEBEC. Furthermore, that any conflict arising from the use of this site will be resolved by arbitration in the State of MONTREAL,QUEBEC according to the rules of the American Arbitration Association and MONTREAL,QUEBEC law. All content, pages and materials displayed on this Internet site, and any other materials list, or any additional information provided to you through this site or obtained from a BCM GLOBAL TRADER representative, by email or fax, including any other materials in any site(s) owned or operated by BCM GLOBAL TRADER , including but not limited to the text, images, audio and /or video, including software, but not limited to any images or files incorporated in or generated by the software or data accompanying such software either is the property of BCM GLOBAL TRADER and are also protected by United States and international copyright and trademark laws.
The compilation of all aforementioned materials comprised in this site or any other sites owned and operated by BCM GLOBAL TRADER are the exclusive properties of BCM GLOBAL TRADER and are protected by the United States and international copyright laws. Any infringement will cause BCM GLOBAL TRADER to seek the proper remedies immediately and without hesitation. You are strictly prohibited from copying, reproducing, republishing, reprinting, modifying, adapting, exhibiting, translating, distributing, transmitting, uploading, posting, selling, publicly performing, reverse engineering, disassembling, or in any way exploiting any of the materials in whole or in part, except as needed by your counsel of financial adviser on a need to know basis only, and provided you keep intact all copyright and other proprietary notifications and intellectual property belonging to BCM GLOBAL TRADER . Any unauthorized use of these materials may violate copyright laws, trademark laws, the laws of privacy and publicity, and communications regulations and statutes, and may subject the violator to criminal penalties.
The trademarks, logos, and service marks collectively referred as the "Trademarks" displayed on this site or any other sites owned or operated by BCM GLOBAL TRADER are registered, pending, registered, or unregistered Trademarks ofBCM GLOBAL TRADER . A user of this site may not use any of BCM CONSULTANTS's Trademarks, Service marks or designs. Moreover a user may not use any such Trademarks or Service Marks in any manner that is likely to cause confusion among customers, dilutes the Trademarks, or in any manner that disparages or discredits the standing of BCM GLOBAL TRADER . You are also advised that BCM GLOBAL TRADER will aggressively enforce all of its intellectual property rights to the fullest extent of all applicable laws.
The trademarks, logos, and service marks collectively referred as the "Trademarks" displayed on this site or any other sites owned or operated by BCM GLOBAL TRADER are registered, pending, registered, or unregistered Trademarks ofBCM GLOBAL TRADER . A user of this site may not use any of BCM CONSULTANTS's Trademarks, Service marks or designs. Moreover a user may not use any such Trademarks or Service Marks in any manner that is likely to cause confusion among customers, dilutes the Trademarks, or in any manner that disparages or discredits the standing of BCM GLOBAL TRADER . You are also advised that BCM GLOBAL TRADER will aggressively enforce all of its intellectual property rights to the fullest extent of all applicable laws.
FURTHER DISCLAIMERS
This Site and all sites owned and operated by BCM GLOBAL TRADER are controlled by its respective owners from its offices located in the State of MONTREAL,QUEBEC, United States of America. It can be accessed from all fifty states, as well as from all countries in the world. As each of these places has laws that may be different from those of the state of MONTREAL,QUEBEC, by accessing this site both, you and the Owner, agree that the statutes and laws of the state of MONTREAL,QUEBEC, without regard to its conflicts, will apply to all matters arising out of, or relating to, use of this Site and/or any other sites owned and operated by BCM GLOBAL TRADER and this user agreement. You further agree that any action to enforce this User Agreement, or to resolve any dispute arising from, or related to your visit to or use of this site or any other site owned and operated by BCM CONSULTANTS,LLC , will be submitted to final and binding arbitration before one arbitrator in the State of MONTREAL,QUEBEC, in accordance with the procedural rules of the American Arbitration Association and MONTREAL,QUEBEC law. All suggestions, feedback, ideas or information that you may communicate to the Company through this Site or otherwise submitted or offered in connection with your use of this Site or the business opportunities we offer (collectively "Submissions") will forever be the property of BCM GLOBAL TRADER.BCM GLOBAL TRADER will have exclusive ownership of all present and future existing rights to the Submission of every kind everywhere and will be entitled to use the Submission for commercial purposes. You acknowledge that you are and will remain solely responsible for the Submission, including its legality and appropriateness. In addition, you acknowledge that any Submission you make does not violate any rights of any third parties, including, but not limited to, personal or proprietary rights. This Agreement is effective and in full force until terminated by either you or BCM CONSULTANTS,LLC .
BCM GLOBAL TRADER, LLC may terminate this Agreement at any time and without notice, as well as deny you access to this Site, if in BCM CONSULTANTS' sole discretion you fail to comply with any term or condition of this Agreement. You may also terminate this Agreement at any time. Upon termination by either party, you agree to destroy promptly all materials, including all copies thereof, downloaded or otherwise obtained from this Site or any BCM GLOBAL TRADER representatives.
PRICE AND PAYMENTPER MT (Depend on the Quantity, please send your request to us and in 24 to 48 hours we will be able to send you a quotation).(1 MT=20 BAGS OF 50 KG)
OPTION 1:
Payment by Fully Funded Letter of Credit Irrevocable Transferable and Revolving from prime bank for the whole quantity of the contract period with a minimum of 12 months payable 100 % automatically each month upon reception and verification of the shipping document for each vessel.
This option requires from the seller a 2% Performance Bond. Price also is confirmed for the contract period.
OPTION 2:
Payment by conditional MT 103-23 shipment by shipment, covering only the cost of one shipment payable 100% Cash Wire transfer against receipt and verification of Shipping Documents for each vessel.
This option does not require from the seller a 2 % Performance Bond because this option normally is used for spot deal contract or contract of minimum 12 months but with payment for each shipment.
The price is not confirmed for the contract period of 12 months in case the buyer chooses to sign a long term contract with a payment per shipment. Each month, BCM will send the price for every new shipment because of the world market price.
In 1992, the Group that we work with in Brazil became the major shareholder of this textile plant facility in Brazil. Almost extinct at the time, the industry was quickly rebuilt and its infrastructure revamped. The world's most modern air jet loom machinery from the Tsudakoma Company was installed, as well as Jet Spine and Open End spinning machines.
Equipped with the most advanced technology, our textile factory recently received the ISO 9002 certification.
The plant is one of the country's main producers of bedsheet and tablecloth fabrics. It supplies mainly the market demand of São Paulo and Mercosur.
